Use for fully automated drum securing on pallets

Drumclip Automatic Strapping Line (DASL)

The Drumclip Automatic Strapping Line (DASL) is a fully automated, integrated system that securely fastens drums on pallets using Drumclip Technology and PET strapping machines like Cyklop. By replacing plastic wrapping, it eliminates extra securing products and improves transport safety, logistics efficiency, and sustainability.

DASLDASL

Fully Automated, Consistently Reliable

Securing drums by hand is labour-intensive and hard to standardize, while plastic wrapping adds waste, cost, and an extra step to every pallet. DASL removes both. The line automatically positions Drumclips and applies PET strapping in a fixed, repeatable process, configured to your set-up.

Contact us

The result is consistent securing on every pallet, less manual handling, and lower operating costs. By replacing plastic wrapping, DASL also reduces CO2 emissions and waste, while improving logistics efficiency and transport safety.

How does DASL work?

Step 1: Drums are placed on a pallet in sets of two or four and transported via a pallet conveyor belt

Step 2: Two Drumclips are automatically positioned, after which the vertical strap is secured over the drums and pallet

Step 3: The pallet is transferred to the horizontal strapping machine for horizontal strapping

Step 4: The drums are securely fastened to the pallet and can be taken out of the line

Technical Specifications

System DimensionsL 6.05m × W 4.25m × H 3.11m
Power Supply 400V / 50Hz, 8kW
Air Requirements 6 bar, 100L/hour (option for full electric operation)
Strapping MaterialPET strapping by Cyclop, Signode and comparable strapping
Max Throughput 45 pallets/hour
Country of origin The Netherlands
Automation System Yaskawa GP7 robotic arm + Cognex vision system

This is an indicative set-up, customizable to client specifications.

The Drumclip Automatic Strapping Line is a collaboration between Amtra Engineering B.V. and Geba Innovations B.V.
Interested in this solution? Sign up for our demo days to see the test model in action and discuss the possibilities for your set-up.

DASL Demo Days

Ready to give Drumclip a try?

Request a sample kit
